Java多线程基础

Java多线程基础

###　线程的出现

• 线程可以认为是轻量级的进程，所以线程的创建、销毁比进程更快
• 在多核CPU中，利用多线程可以实现真正意义的并行执行（单核cpu中线程是通过cpu时间片不断切换执行的，在任意时刻只会有一个线程会被cpu调度）
• 在一个应用进程中，会存在多个同时执行的任务，如果其中一个任务被阻塞，将会导致其他任务也会被阻塞。通过对不同任务创建不同的线程去处理，可以提升程序的实时性

线程生命周期(6种状态)

NEW、RUNNABLE、BLOCKED、WAITING、TIME_WAITING、TERMINATED（详情见Thread源码）

• NEW：初始状态，线程，但是还没有调用线程的start方法
• RUNNABLE：运行状态，JAVA把操作系统中线程的就绪和运行两种状态统一称为“运行中”
• BLOCKED：阻塞状态，表示线程进入等待状态，线程因为某种原因放弃了CPU使用权，阻塞分以下几种情况
  • 等待阻塞：运行的线程执行wait方法（只有获得锁，才能执行wait方法），jvm会把当前的线程放入到等待队列
  • 同步阻塞：运行的线程在获取对象的同步锁时，如果该同步锁被其他线程占用了，那么jvm会把当前线程放入到锁池中
  • 其他阻塞：运行的线程执行了Thread.sleep或者join方法，或者发出了IO请求时，jvm会帮当前线程设置为阻塞状态，当sleep结束、join线程终止、io处理完毕，线程恢复
  • TIME_WAITING：超时等待状态，超时后自动返回
  • TERMINATED：终止状态，表示当前线程执行完毕

java

/**
 * A thread state.  A thread can be in one of the following states:
 * <ul>
 * <li>{@link #NEW}<br>
 *     A thread that has not yet started is in this state.
 *     </li>
 * <li>{@link #RUNNABLE}<br>
 *     A thread executing in the Java virtual machine is in this state.
 *     </li>
 * <li>{@link #BLOCKED}<br>
 *     A thread that is blocked waiting for a monitor lock
 *     is in this state.
 *     </li>
 * <li>{@link #WAITING}<br>
 *     A thread that is waiting indefinitely for another thread to
 *     perform a particular action is in this state.
 *     </li>
 * <li>{@link #TIMED_WAITING}<br>
 *     A thread that is waiting for another thread to perform an action
 *     for up to a specified waiting time is in this state.
 *     </li>
 * <li>{@link #TERMINATED}<br>
 *     A thread that has exited is in this state.
 *     </li>
 * </ul>
 *
 * <p>
 * A thread can be in only one state at a given point in time.
 * These states are virtual machine states which do not reflect
 * any operating system thread states.
 *
 * @since   1.5
 * @see #getState
 */
public enum State {
  /**
   * Thread state for a thread which has not yet started.
   */
  NEW,

  /**
   * Thread state for a runnable thread.  A thread in the runnable
   * state is executing in the Java virtual machine but it may
   * be waiting for other resources from the operating system
   * such as processor.
   */
  RUNNABLE,

  /**
   * Thread state for a thread blocked waiting for a monitor lock.
   * A thread in the blocked state is waiting for a monitor lock
   * to enter a synchronized block/method or
   * reenter a synchronized block/method after calling
   * {@link Object#wait() Object.wait}.
   */
  BLOCKED,

  /**
   * Thread state for a waiting thread.
   * A thread is in the waiting state due to calling one of the
   * following methods:
   * <ul>
   *   <li>{@link Object#wait() Object.wait} with no timeout</li>
   *   <li>{@link #join() Thread.join} with no timeout</li>
   *   <li>{@link LockSupport#park() LockSupport.park}</li>
   * </ul>
   *
   * <p>A thread in the waiting state is waiting for another thread to
   * perform a particular action.
   *
   * For example, a thread that has called <tt>Object.wait()</tt>
   * on an object is waiting for another thread to call
   * <tt>Object.notify()</tt> or <tt>Object.notifyAll()</tt> on
   * that object. A thread that has called <tt>Thread.join()</tt>
   * is waiting for a specified thread to terminate.
   */
  WAITING,

  /**
   * Thread state for a waiting thread with a specified waiting time.
   * A thread is in the timed waiting state due to calling one of
   * the following methods with a specified positive waiting time:
   * <ul>
   *   <li>{@link #sleep Thread.sleep}</li>
   *   <li>{@link Object#wait(long) Object.wait} with timeout</li>
   *   <li>{@link #join(long) Thread.join} with timeout</li>
   *   <li>{@link LockSupport#parkNanos LockSupport.parkNanos}</li>
   *   <li>{@link LockSupport#parkUntil LockSupport.parkUntil}</li>
   * </ul>
   */
  TIMED_WAITING,

  /**
   * Thread state for a terminated thread.
   * The thread has completed execution.
   */
  TERMINATED;
}

查看线程的状态及jvm内存监控可以参考以下命令：

• jps:查看本机的Java中进程信息

• jstack:打印线程的栈信息,制作线程Dump（jstack pid<进程id>）

• jmap:打印内存映射,制作堆Dump（jmap -dump:format-b,file=保存文件路径）

• jstat:性能监控工具

• jhat:内存分析工具 jhat -port file<dump文件>

• jconsole:简易的可视化控制台

• jvisualvm:功能强大的控制台

线程的创建

• 继承Thread类（本质是对Runnable接口的实现）
• 实现Runnable接口
• 使用ExecutorService
• Callable、Future（带返回值）

启动线程的唯一方法就是通过Thread类的start方法（srart方法是一个native方法，它会启动一个新的线程，并执行run方法）

java

/** Thread class source code */
public class Thread implements Runnable {
  /* Make sure registerNatives is the first thing <clinit> does. */
  private static native void registerNatives();
  static {
    registerNatives();
  }

  /* What will be run. */
  private Runnable target;

  public Thread(Runnable target) {
    init(null, target, "Thread-" + nextThreadNum(), 0);
  }

  public Thread(Runnable target, String name) {
    init(null, target, name, 0);
  }

  public synchronized void start() {
    /**
     * This method is not invoked for the main method thread or "system"
     * group threads created/set up by the VM. Any new functionality added
     * to this method in the future may have to also be added to the VM.
     *
     * A zero status value corresponds to state "NEW".
     */
    if (threadStatus != 0)
      throw new IllegalThreadStateException();

    /* Notify the group that this thread is about to be started
     * so that it can be added to the group's list of threads
     * and the group's unstarted count can be decremented. */
    group.add(this);

    boolean started = false;
    try {
      start0();
      started = true;
    } finally {
      try {
        if (!started) {
          group.threadStartFailed(this);
        }
      } catch (Throwable ignore) {
        /* do nothing. If start0 threw a Throwable then
             it will be passed up the call stack */
      }
    }
  }
  /** native method */
  private native void start0();

  @Override
  public void run() {
    if (target != null) {
      target.run();
    }
  }
}

jvm线程创建、启动源码

打开OpenJDK / jdk8 / jdk8 / jdk源码，找到文件->src/share/native/java/lang/Thread.c @ 2362:00cd9dc3c2b5，可以看到java中Thread类中调用的本地方法，在虚拟机jvm.cpp文件中的定义，以及映射关系，本地方法通过JNI技术暴露给外部调用。

Thread.c文件源码：

c++

#include "jni.h"
#include "jvm.h"
#include "java_lang_Thread.h"

#define THD "Ljava/lang/Thread;"
#define OBJ "Ljava/lang/Object;"
#define STE "Ljava/lang/StackTraceElement;"
#define ARRAY_LENGTH(a) (sizeof(a)/sizeof(a[0]))

static JNINativeMethod methods[] = {
    {"start0",           "()V",        (void *)&JVM_StartThread},
    {"stop0",            "(" OBJ ")V", (void *)&JVM_StopThread},
    {"isAlive",          "()Z",        (void *)&JVM_IsThreadAlive},
    {"suspend0",         "()V",        (void *)&JVM_SuspendThread},
    {"resume0",          "()V",        (void *)&JVM_ResumeThread},
    {"setPriority0",     "(I)V",       (void *)&JVM_SetThreadPriority},
    {"yield",            "()V",        (void *)&JVM_Yield},
    {"sleep",            "(J)V",       (void *)&JVM_Sleep},
    {"currentThread",    "()" THD,     (void *)&JVM_CurrentThread},
    {"countStackFrames", "()I",        (void *)&JVM_CountStackFrames},
    {"interrupt0",       "()V",        (void *)&JVM_Interrupt},
    {"isInterrupted",    "(Z)Z",       (void *)&JVM_IsInterrupted},
    {"holdsLock",        "(" OBJ ")Z", (void *)&JVM_HoldsLock},
    {"getThreads",        "()[" THD,   (void *)&JVM_GetAllThreads},
    {"dumpThreads",      "([" THD ")[[" STE, (void *)&JVM_DumpThreads},
};

#undef THD
#undef OBJ
#undef STE

JNIEXPORT void JNICALL
Java_java_lang_Thread_registerNatives(JNIEnv *env, jclass cls)
{
    (*env)->RegisterNatives(env, cls, methods, ARRAY_LENGTH(methods));
}

/src/share/vm/prims/jvm.cpp源码（线程启动）：

c++

JVM_ENTRY(void, JVM_StartThread(JNIEnv* env, jobject jthread))
  JVMWrapper("JVM_StartThread");
  JavaThread *native_thread = NULL;

  // We cannot hold the Threads_lock when we throw an exception,
  // due to rank ordering issues. Example:  we might need to grab the
  // Heap_lock while we construct the exception.
  bool throw_illegal_thread_state = false;

  // We must release the Threads_lock before we can post a jvmti event
  // in Thread::start.
  {
    // Ensure that the C++ Thread and OSThread structures aren't freed before
    // we operate.
    MutexLocker mu(Threads_lock);

    // Since JDK 5 the java.lang.Thread threadStatus is used to prevent
    // re-starting an already started thread, so we should usually find
    // that the JavaThread is null. However for a JNI attached thread
    // there is a small window between the Thread object being created
    // (with its JavaThread set) and the update to its threadStatus, so we
    // have to check for this
    if (java_lang_Thread::thread(JNIHandles::resolve_non_null(jthread)) != NULL) {
      throw_illegal_thread_state = true;
    } else {
      // We could also check the stillborn flag to see if this thread was already stopped, but
      // for historical reasons we let the thread detect that itself when it starts running

      jlong size =
             java_lang_Thread::stackSize(JNIHandles::resolve_non_null(jthread));
      // Allocate the C++ Thread structure and create the native thread.  The
      // stack size retrieved from java is signed, but the constructor takes
      // size_t (an unsigned type), so avoid passing negative values which would
      // result in really large stacks.
      size_t sz = size > 0 ? (size_t) size : 0;
      native_thread = new JavaThread(&thread_entry, sz);

      // At this point it may be possible that no osthread was created for the
      // JavaThread due to lack of memory. Check for this situation and throw
      // an exception if necessary. Eventually we may want to change this so
      // that we only grab the lock if the thread was created successfully -
      // then we can also do this check and throw the exception in the
      // JavaThread constructor.
      if (native_thread->osthread() != NULL) {
        // Note: the current thread is not being used within "prepare".
        native_thread->prepare(jthread);
      }
    }
  }

  if (throw_illegal_thread_state) {
    THROW(vmSymbols::java_lang_IllegalThreadStateException());
  }

  assert(native_thread != NULL, "Starting null thread?");

  if (native_thread->osthread() == NULL) {
    // No one should hold a reference to the 'native_thread'.
    delete native_thread;
    if (JvmtiExport::should_post_resource_exhausted()) {
      JvmtiExport::post_resource_exhausted(
        JVMTI_RESOURCE_EXHAUSTED_OOM_ERROR | JVMTI_RESOURCE_EXHAUSTED_THREADS,
        "unable to create new native thread");
    }
    THROW_MSG(vmSymbols::java_lang_OutOfMemoryError(),
              "unable to create new native thread");
  }

  Thread::start(native_thread);

JVM_END

从源码native_thread = new JavaThread(&thread_entry, sz);可以看出，本地线程native_thread是通过创建JAVA线程来创建的，通过Thread::start(native_thread)来启动线程，最终通过操作系统来创建线程。

/src/share/vm/runtime/thread.cpp源码：

c++

void Thread::start(Thread* thread) {
  trace("start", thread);
  // Start is different from resume in that its safety is guaranteed by context or
  // being called from a Java method synchronized on the Thread object.
  if (!DisableStartThread) {
    if (thread->is_Java_thread()) {
      // Initialize the thread state to RUNNABLE before starting this thread.
      // Can not set it after the thread started because we do not know the
      // exact thread state at that time. It could be in MONITOR_WAIT or
      // in SLEEPING or some other state.
      java_lang_Thread::set_thread_status(((JavaThread*)thread)->threadObj(),
                                          java_lang_Thread::RUNNABLE);
    }
    os::start_thread(thread);
  }
}

jvm中断线程方法

/src/share/vm/prims/jvm.cpp源码，jvm最后调用Thread.cpp中的is_interrupted方法去中断某个线程

c++

JVM_ENTRY(void, JVM_Interrupt(JNIEnv* env, jobject jthread))
  JVMWrapper("JVM_Interrupt");

  // Ensure that the C++ Thread and OSThread structures aren't freed before we operate
  oop java_thread = JNIHandles::resolve_non_null(jthread);
  MutexLockerEx ml(thread->threadObj() == java_thread ? NULL : Threads_lock);
  // We need to re-resolve the java_thread, since a GC might have happened during the
  // acquire of the lock
  JavaThread* thr = java_lang_Thread::thread(JNIHandles::resolve_non_null(jthread));
  if (thr != NULL) {
    Thread::interrupt(thr);
  }
JVM_END

JVM_QUICK_ENTRY(jboolean, JVM_IsInterrupted(JNIEnv* env, jobject jthread, jboolean clear_interrupted))
  JVMWrapper("JVM_IsInterrupted");

  // Ensure that the C++ Thread and OSThread structures aren't freed before we operate
  oop java_thread = JNIHandles::resolve_non_null(jthread);
  MutexLockerEx ml(thread->threadObj() == java_thread ? NULL : Threads_lock);
  // We need to re-resolve the java_thread, since a GC might have happened during the
  // acquire of the lock
  JavaThread* thr = java_lang_Thread::thread(JNIHandles::resolve_non_null(jthread));
  if (thr == NULL) {
    return JNI_FALSE;
  } else {
    return (jboolean) Thread::is_interrupted(thr, clear_interrupted != 0);
  }
JVM_END

/src/share/vm/runtime/thread.cpp源码，最终是调用操作系统的is_interrupted方法中断线程

c++

void Thread::interrupt(Thread* thread) {
  trace("interrupt", thread);
  debug_only(check_for_dangling_thread_pointer(thread);)
  os::interrupt(thread);
}

bool Thread::is_interrupted(Thread* thread, bool clear_interrupted) {
  trace("is_interrupted", thread);
  debug_only(check_for_dangling_thread_pointer(thread);)
  // Note:  If clear_interrupted==false, this simply fetches and
  // returns the value of the field osthread()->interrupted().
  return os::is_interrupted(thread, clear_interrupted);
}

/src/os/linux/vm/os_linux.cpp源代码（这里已linux操作系统平台为例），通过调用OSThread类的set_interrupted(true)，将成员变量_interrupted设置为true，来设置线程中断，默认为false

c++

void os::interrupt(Thread* thread) {
  assert(Thread::current() == thread || Threads_lock->owned_by_self(),
    "possibility of dangling Thread pointer");

  OSThread* osthread = thread->osthread();

  if (!osthread->interrupted()) {
    osthread->set_interrupted(true);
    // More than one thread can get here with the same value of osthread,
    // resulting in multiple notifications.  We do, however, want the store
    // to interrupted() to be visible to other threads before we execute unpark().
    OrderAccess::fence();
    ParkEvent * const slp = thread->_SleepEvent ;
    if (slp != NULL) slp->unpark() ;
  }

  // For JSR166. Unpark even if interrupt status already was set
  if (thread->is_Java_thread())
    ((JavaThread*)thread)->parker()->unpark();

  ParkEvent * ev = thread->_ParkEvent ;
  if (ev != NULL) ev->unpark() ;

}

bool os::is_interrupted(Thread* thread, bool clear_interrupted) {
  assert(Thread::current() == thread || Threads_lock->owned_by_self(),
    "possibility of dangling Thread pointer");

  OSThread* osthread = thread->osthread();

  bool interrupted = osthread->interrupted();

  if (interrupted && clear_interrupted) {
    osthread->set_interrupted(false);
    // consider thread->_SleepEvent->reset() ... optional optimization
  }

  return interrupted;
}

/src/share/vm/runtime/osThread.hpp源代码

c++

class OSThread: public CHeapObj<mtThread> {
 friend class VMStructs;
 private:
  /** 省略其他代码 */
  volatile ThreadState _state;    // Thread state *hint*
  volatile jint _interrupted;     // Thread.isInterrupted state

  // Note:  _interrupted must be jint, so that Java intrinsics can access it.
  // The value stored there must be either 0 or 1.  It must be possible
  // for Java to emulate Thread.currentThread().isInterrupted() by performing
  // the double indirection Thread::current()->_osthread->_interrupted.

  // Methods
 public:
  void set_state(ThreadState state)                { _state = state; }
  ThreadState get_state()                          { return _state; }

  /** 省略其他代码 */

  volatile bool interrupted() const                 { return _interrupted != 0; }
  void set_interrupted(bool z)                      { _interrupted = z ? 1 : 0; }

  /** ....... 剩余代码省略 */
}

线程Interrupte之后调用Thread.interrupted()复位

Thread.java

java

Thread.interrupted();  // 复位，回到初始状态

public static boolean interrupted() {
  return currentThread().isInterrupted(true);
}

// 本地方法，参考上面已经提到的jvm线程中断源码
private native boolean isInterrupted(boolean ClearInterrupted);

中断一个处于阻塞状态(sleep/wait/join/…)的线程，会先复位，再抛出异常（为什么会抛出异常可以参考jvm.cpp文件中的JVM_Sleep方法）

c++

JVM_ENTRY(void, JVM_Sleep(JNIEnv* env, jclass threadClass, jlong millis))
  JVMWrapper("JVM_Sleep");

  if (millis < 0) {
    THROW_MSG(vmSymbols::java_lang_IllegalArgumentException(), "timeout value is negative");
  }

  if (Thread::is_interrupted (THREAD, true) && !HAS_PENDING_EXCEPTION) {
    THROW_MSG(vmSymbols::java_lang_InterruptedException(), "sleep interrupted");
  }

  // Save current thread state and restore it at the end of this block.
  // And set new thread state to SLEEPING.
  JavaThreadSleepState jtss(thread);

#ifndef USDT2
  HS_DTRACE_PROBE1(hotspot, thread__sleep__begin, millis);
#else /* USDT2 */
  HOTSPOT_THREAD_SLEEP_BEGIN(
                             millis);
#endif /* USDT2 */

  EventThreadSleep event;

  if (millis == 0) {
    // When ConvertSleepToYield is on, this matches the classic VM implementation of
    // JVM_Sleep. Critical for similar threading behaviour (Win32)
    // It appears that in certain GUI contexts, it may be beneficial to do a short sleep
    // for SOLARIS
    if (ConvertSleepToYield) {
      os::yield();
    } else {
      ThreadState old_state = thread->osthread()->get_state();
      thread->osthread()->set_state(SLEEPING);
      os::sleep(thread, MinSleepInterval, false);
      thread->osthread()->set_state(old_state);
    }
  } else {
    ThreadState old_state = thread->osthread()->get_state();
    thread->osthread()->set_state(SLEEPING);
    if (os::sleep(thread, millis, true) == OS_INTRPT) {
      // An asynchronous exception (e.g., ThreadDeathException) could have been thrown on
      // us while we were sleeping. We do not overwrite those.
      if (!HAS_PENDING_EXCEPTION) {
        if (event.should_commit()) {
          event.set_time(millis);
          event.commit();
        }
#ifndef USDT2
        HS_DTRACE_PROBE1(hotspot, thread__sleep__end,1);
#else /* USDT2 */
        HOTSPOT_THREAD_SLEEP_END(
                                 1);
#endif /* USDT2 */
        // TODO-FIXME: THROW_MSG returns which means we will not call set_state()
        // to properly restore the thread state.  That's likely wrong.
        THROW_MSG(vmSymbols::java_lang_InterruptedException(), "sleep interrupted");
      }
    }
    thread->osthread()->set_state(old_state);
  }
  if (event.should_commit()) {
    event.set_time(millis);
    event.commit();
  }
#ifndef USDT2
  HS_DTRACE_PROBE1(hotspot, thread__sleep__end,0);
#else /* USDT2 */
  HOTSPOT_THREAD_SLEEP_END(
                           0);
#endif /* USDT2 */
JVM_END

实际应用

• 线程池
• zookeeper责任链，异步化任务
• 跑批脚本、对账文件

并发编程相关文章持续更新中…
